    Mppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPS

    Ask Lasest Price
    Brand Name : Kweight
    Model Number : SPH6000TL BL-UP
    Certification : CE/RoHS/UN38.3/MSDS
    Price :
    Payment Terms : L/C, D/A, T/T, D/P, Western Union, MoneyGram
    Supply Ability : 10000 Pieces per Month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Mppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPS

    6000W MPPT 230V Pure Sine Wave Solar Inverter For On Grid Tie System With UPS Function SPH6000TL BL-UP
    Product features:
    >UPS function, 10ms transition
    >4kW charge/discharge power
    >4kw backup power
    >AC-coupled function compatible with third-party inverter
    >1.5 DC/AC ratio, 6kw system with 9kW solar input
    >13.5A solar input current for high power modules
    >VPP interface ready
    >Scalable system configuration
    >Safety standard set by LCD directly
    Datasheet
    SPH3000
    SPH4000
    SPH4600
    SPH5000
    SPH6000
    PV Input data
    Max. recommended PV power (for module STC)
    6600W
    8000W
    9200W
    10500W
    11200W
    Max. DC voltage
    550V
    Start voltage
    120V
    MPP voltage range
    120V-550V/360V
    No. of MPP trackers
    2
    No. of PV strings per MPP tracker
    1
    Max. input current per MPP tracker

    13.5A
    Max. short-circuit current per MPP tracker
    16.5A
    AC Output
    Rated AC output power
    3000W
    4000W
    4600W
    5000W
    6000W
    Max. AC apparent power
    3000VA
    4000VA
    4600VA
    5000VA
    6000VA
    Nominal AC voltage (range)
    230V/(180Vac-270Vac)
    AC grid frequency (range)
    50Hz/60Hz (45Hz-55Hz/55Hz-65Hz)
    Max. output current
    16A
    22A
    22A
    22A
    27A
    Displacement power factor
    0.8leading…0.8lagging
    THDI
    < 3 %
    AC grid connection type
    Single phase
    AC output power(Backup)
    Max. output power
    3000W
    3000W
    3000W
    3000W
    3000W
    Max. output current
    17.4A
    Rated AC output voltage
    230Vac
    Rated AC output frequency
    50/60Hz
    THDv
    <3%
    Switch time
    <10ms
    Battery data
    Battery voltage range
    42~59V
    Max charging and discharging current
    66A
    85A
    85A
    85A
    85A
    Max charging and discharging power
    3000W
    4000W
    4000W
    4000W
    4000W
    Type of battery
    Lithium /Lead-acid
    Efficiency
    MAX. efficiency
    97.2%
    97.3%
    97.4%
    97.5%
    97.6%
    Euro European efficiency
    97.0%
    97.1%
    97.1%
    97.2%
    97.2%
    MPPT efficiency
    ≥99.5%
    Protection devices
    DC switch
    yes
    DC reverse polarity protection
    yes
    AC/DC surge protection
    yes
    Battery reverse protection
    yes
    Output over current protection
    yes
    Output over voltage protection
    yes
    Ground fault monitoring
    yes
    Grid monitoring
    yes
    Integrated all - pole sensitive leakage
    yes
    General data
    Dimensions (W / H / D)in mm
    458/565/188mm
    Weight
    31kg
    Operating temperature range
    -25°C... +60°C
    Nighttime power consumption
    < 10 W
    Topology
    transformerless
    Cooling
    Natural
    Protection degree
    IP65
    Altitude
    2000m
    Relative humidity
    0~100%
    PV DC Connection
    MC4/H4(opt)
    Battery DC Connection
    OT Terminal
    AC connection
    Connector
    Interface:RS232/USB/RF/Wi-Fi
    yes/yes /opt/opt
    Display
    LCD+LED
    Interfaces:RS485/CAN/USB
    Yes
    Monitor : RF/WIFI/GPR
    Optional
    Warranty: 5 years /10 years
    yes / opt
