    Home 51.2V 100Ah Lithium Battery Module 48 Volt 100ah Lithium Ion Battery

    Ask Lasest Price
    Brand Name : Kweight
    Model Number : PVE48100
    Supply Ability : 10000 Pack/Packs per Month
    Price :
    Certification : CE/RoHS/UN38.3/MSDS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    Home 51.2V 100Ah Lithium Battery Module 48 Volt 100ah Lithium Ion Battery

    48V 100ah Lifepo4 Batteries Module For Home Energy Storage System


    Product Description


    MAINTENANCE FREE
    No any extra cost
    MORE HOURS OF POWERQuick charge,always stand by
    SAFE AND RELIABLEThe safest LFP batteny cel
    LONG LIFESPAN


    3000 cycle @2580%DOD
    HIGH ENERGY DENSITY
    More energy but more portable
    LOW INTERNAL RESISTANCE
    Excellent discharge performance


    Product Usage


    Modular Design

    Modular Design Allowing Extension Whenever Wanted, Allows For Expansion From 2.4KWh to 15KWh System, And Can Parallel To Get Bigger Energy Capacity.


    High Power Output

    Kweight Battery Storage System Has High Output Power And Usable Energy Ratio, They Can Reach 95% Usable Ratio.


    ->Standard 48V system
    ->The most popular battery capacity: 5KWh
    ->CAN2.0/RS485/RS232
    ->Total energy extends to 30KWh by 6 parallel battery packs
    ->Installation: Floor Wall mounted
    ->Matched with various famous brand inverters


    Company Profile


    Shenzhen Kweight Development Co., Ltd. is one of the leading lead-acid battery manufacturer in China. Our factory is located in Longgang District of Shenzhen & Yangquan, Shanxi in China and covers an area of 50,000 square meters. There are over 200 workers and 15 members in charge of engineering, management and quality control.Our company specializes in manufacturing 2V, 4V, 6V and 12V series maintenance free lead-acid battery, Gel battery, Deep cycle battery, solar battery, front access(gel) battery, OPzV and OPzS battery etc.. We have hundreds of models and specifications for selection, and all of products are compliance with CE, RoHS and UL. Our quality is strictly controlled as per ISO9001:2008 quality system and every piece of our battery is inspected by advanced testing machines before shipment. Our batteries are exported to North America, South America, East & West Europe, Australia & Africa relying on their good quality and competitive prices.Please feel free to contact us for further information.



    Cells Specification
    NoItemGeneral ParameterRemark
    1Capacity

    Typical:100Ah

    Min:98Ah

    Standard discharge after Standard charge
    2Nominal Voltage3.2VMean Operation Voltage
    3Internal Impedance≤0.4mΩ

    Under 20±5℃ Environment Temperature , the

    Usage Frequency of Fully Charge( 1KHz) , Use

    AC Internal Impedance test machine to test

    4Standard charge

    Constant Current 0.5C5A

    Constant Voltage 3.6V

    0.02C5A cut-off

    Charge time : Approx2.5h
    5Rapid Charge

    Constant Current 1C5A

    Constant Voltage 3.6V

    0.02C5A cut-off

    Charge time : Approx1.5h
    6Standard Charge Cut-off Voltage3.6V

    Voltage of the battery when the Charge is

    stopped

    7Standard Discharge Cut-off Voltage2.5V

    Voltage of the battery when the discharge

    is stopped

    8Standard discharge

    Constant current 1C5A

    end voltage 2.5 V

    100A
    9

    Maximum discharge

    current

    Constant current:1C5A

    end voltage:2.5 V

    100A@≧0℃
    10Dimension

    Thickness:48±0.5mm

    Width:173.9±0.8mm

    Height:120.6±0.8mm

    Initial Dimension
    12Operating Temperature Range

    Temperature:-20~60℃

    Humidity: ≤65%RH

    Recommended charge/discharge current≤1I1

    (50A),when cell temperature is lower than0℃,

    Recommended cool the cell, when cell

    temperature is higher than 60℃

    13Storage Temperature Range-20℃ ~25℃

    Recommend( 25±3℃ );≤90%RH storage

    moisture range.


    Home 51.2V 100Ah Lithium Battery Module 48 Volt 100ah Lithium Ion Battery

    Home 51.2V 100Ah Lithium Battery Module 48 Volt 100ah Lithium Ion Battery

    Production workshop


    Home 51.2V 100Ah Lithium Battery Module 48 Volt 100ah Lithium Ion Battery

    Home 51.2V 100Ah Lithium Battery Module 48 Volt 100ah Lithium Ion Battery



    Home 51.2V 100Ah Lithium Battery Module 48 Volt 100ah Lithium Ion Battery

    FAQ:


    Q1:Are you a manufacturer or trading company?
    A1: We are a manufacturer, a leading company in the global battery field.


    Q2:How about your after-sale service?

    A2: We can offer you timely and best after-sale service. So far we have our branch offices in many overseas countries like USA, Canada, the UK, France, Brazil, Japan, Korea, Philippines, Malaysia, India, Australia, and other Asia and African countries. It makes our after-sale service very easy and effective to reachyou. Also our 24 hours online inquiry service is available.


    Q3:What's your delivery time?

    A3: It depends on the specific products and the quantity you need.


    Q4:What certifications does your company have?
    A4: Our company had passed the CE&RoHS, ISO19001&ISO14001 certifications.


    Q5: Why should I choose your company?
    A5: A. Our belief : assured long-lasting quality, reliable long-existing service.


    B. Our competence: quality and technology is our key competitive advantage, wins a good reputation and track record for us.
    C. Our dream: provide every customer with the suitable high quality battery for the further business cooperation.
    D. Our honor : our batteries served as the power supplier for 2010 Singapore Youth Olympic Games for their reliable quality and stable high performance.
