    Home 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel System

    Ask Lasest Price
    Brand Name : Kweight
    Supply Ability : 10000 Acre/Acres per Month
    Price :
    Model Number : 5KW-Kit
    Certification : CE/RoHS/UN38.3/MSDS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Home 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel System

    Off Grid Solar Panel System 1KW 2KW 3KW 5KW Home Solar Energy System With Battery


    Product Description


    The cloud monitors the operation of devices in real time, and supports theuse of mobile phones, tablets, and laptops for monitoring (via WiFi)


    1. LCD display2. Status indicator3. Charging indicator
    4. Fault indicator
    5. Function buttons
    6.AC input
    7.WiFi/GPRS communication port

    8.USB communication port

    9.CAN communication Port
    10. RS485 communication Port
    11. Dry contact
    12. PV input
    13. Power on/off switch
    14. Battery input
    15. Parallel communication ports
    16. Current sharing ports17. AC output
    18. Circuit breaker


    PACKING & SHIPPING


    SCIENTIFIC AND PROFESSIONAL
    SHORTCUT SERVICECaring for your service let commoditsecurity at your side
    First time deliver guarantee rate


    Simple Operation
    The convenient operation interfacemakes it easier for you to deal withall kinds of emergencies


    CERTIFICATES
    WITH CEMSDSUN38.3,ULFCCROHS AND OTHER PROFESSIONAL IDENTIFICATION

    CERTIFICATES


    Inverter Spec.
    Battery Voltage48VDC
    Battery TypeLithium/Lead-acid
    Rated Power5000VA/ 5000W
    Parallel CapabilityYes, 6 units maximum

    AC Voltage Regulation

    (Battery Mode)

    230VAC ± 5% @ 50/60Hz

    110VAC ± 5% @ 50/60Hz

    Surge Power10000VA
    Efficiency (Peak)93%
    WaveformPure sine wave
    Transfer Time10ms typical, 20ms Max
    Maximum PV Array Power6000W
    MPPT Range @ Operating Voltage120VDC ~ 430VDC
    Number of Independent MPP Trackers/ Strings Per MPP Tracker1/1

    Maximum PV Array Open

    Circuit Voltage

    450VDC
    Charge Current80A
    AC Input Voltage230 VAC 110AVC
    Selectable Voltage Range170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances)
    Frequency Range50Hz/60Hz (Auto sensing)
    Dimension (W/H/D)330/485/135mm
    Net Weight12kgs
    Battery Spec.
    Nominal Voltage48V/51.2V
    Capacity100Ah/200Ah
    Energy5120Wh/10240Wh
    Internal Resistance≤80mΩ
    Cycle Life≥6000 cycles @ 80% DOD, 25℃, 0.5C
    ≥5000 cycles @ 80% DOD, 40℃, 0.5C
    Design Life≥10 years
    Charge Cut-off Voltage57.6V±0.5V
    Standard charge50A
    Max. Continuous Work Current100A
    Discharge Cut-off Voltage43.2V±0.5V
    Charge Temperature0℃~45℃
    Discharge Temperature-20℃~55℃
    Storage Temperature-20℃~45℃ @ 60%±25% relative humidity
    Dimensions10KWh Size:604 x470 x198(238)mm 5KWh Size : 600 x345 x160(200)mm
    Weight10KWh Approx:≈86kg 5KWh Approx:≈45kg
    Protocol (optional)RS232-PC RS485(B)-PC RS485(A)-Inverter CANBUS-Inverter


    Home 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel System

    Home 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel System

    Home 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel System


    Home 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel System


    Home 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel SystemHome 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel System


    Home 5kw 3kw Off Grid Power Systems Monocrystalline Silicon Solar Panel System

    FAQ

    1. Is the freight on the website accurate?

    -Please contact us before you order,the default freight on the website is basically calculated according to the usual air freight price, different countries,differentorder weight, different freight. Please contact us in time, we will provide you with the best shipping way and accurate freight.

    2. The delivery time set on your system is 45days, do I really need to wait so long?
    -No, if it is not a customized order, we usually send it out within 15 working days.

    3.Does the shipping way to our country include tax?
    -It depends on the country and the shipping way you choose. Most Asiancountries, most European countries, the United States, and Canada have tax-included shipping channels.

    4. Why the transportationtime is so long and the tracking number not updated in nearly a month?
    -As you know, the battery (especially the high-powerbattery) is special commodity, the terms of transportation are very strict. We transit our products by formal DG logistic channel,it is more slowly than the normal logistic, because it needs wait the DG ship/train schedule. Due to the particularity of theproduct and logistic, the tracking number we provide will not updated before the goods passes the customs in your country. Don'tworry, your goods is still in normal transit. When the goods passes through the customs in your country, the tracking informationwill updated, and you will receive it within 3-5 days.

    5. Is this product safe? -Passed the overcharge, over discharge, over
    temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance.

    6. How to confirm the high quality of the product you sent me?
    -Our batteries are all grade A, No matter how many you order, we will test each product before sending out.

    7. The battery is so heavy, will it damaged easily on the road?
    -This is also a matter of great concerm to us.After long-term improvement and verification, our packaging is now very safe and reliable. When you open the package, you will definitely feel our sincerity.

    8. Is it OK to print my logo on the product?
    -Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
